FTTA ODVA IP67 Connector Waterproof MPO LC SC Fiber Optic Patch Cord

Product Categories

CFOFC Communications Ltd.

Contact Now

FTTA ODVA IP67 Connector Waterproof MPO LC SC Fiber Optic Patch Cord

Ask Lasest Price
Brand Name :	CFOFC
Model Number :	ODVA IP67 Connector Waterproof patch cord
Certification :	ISO9001/ REACH / ROHS
Price :	Negotiable
Payment Terms :	L/C, T/T,Paypal, Western Union
Supply Ability :	30,000 pcs per month
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

FTTA ODVA IP67 Connector Waterproof MPO LC SC Fiber Optic Patch Cord

ODVA Fiber Optical Patch Cable LC / SC / MPO IP67 Waterproof Jacket

Description OF ODVA Fiber Optical Patch

ODVA-compliant connectors specifically for harsh environment applications, such as WiMax, Long Term Evolution (LTE), and Remote Radio Heads using Fiber To The Antenna (FTTA) connectivity, which require rugged connector and cable assemblies suitable for outdoor use. Designated the LC Series, UNIFIBER offers the broadest ODVA-compliant fiber-optic connector portfolio in the industry, providing both full-metal and plastic versions of the IP67-rated interconnects.

Specification OF ODVA Fiber Optical Patch

Fiber Count	1,2,12 core
Fiber Type	SM G652D, SM G657A, or MM 50/125 or MM 62.5/125
Connectors	ODVA SC/LC/MPO
Cable Diameter	4.8/7.0
Cable Jacket	LSZH,TPU,PE
Cable Length	1~150m or Customized

Performance Level			Standard		Elite
Connector	Mode	Endface	IL(max) (dB)	RL(min) (dB)	IL(max) (dB)	RL(min) (dB)
MPO/MTP	SM	12F/APC	≤0.70	≥60	≤0.35	≥60
		24F/APC	≤0.75	≥60	≤0.35	≥60
		48F/APC	≤0.75	≥60
	MM	12F/PC	≤0.50	≥20	≤0.35	≥20
		24F/PC	≤0.50	≥20	≤0.35	≥20
		48F/PC	≤0.50	≥20
LC/SC/FC/ST	SM	APC	≤0.30	≥60	≤0.10	≥60
	SM	UPC	≤0.20	≥50	≤0.10	≥50
	MM	PC	≤0.20	≥30	≤0.10	≥30

Features OF ODVA Fiber Optical Patch

Bayonet mechanical latch with IP67 grade
Suitable for different temperature and weather, harsh environment usage
Duplex LC, simplex SC or MPO connector with good repeat ability and interchangeability

Application OF ODVA Fiber Optical Patch

Multi-purpose Outdoor
For connection between distribution box and RRH
Deployment in Remote Radio Head cell tower applications
Remote interface application such as FTTx or towers
Mobile routers and internet hardware
Harsh environments where chemical, corrosive gases and liquids are common
Used for based station, RRU, RRH, LTE, BBU

FTTA ODVA IP67 Connector Waterproof MPO LC SC Fiber Optic Patch Cord

The reason why Choose us:

1. On time delivery

2. Factory outlet

3. Customization

4. Large product inventory with massive production line

5. Product distribution involves multi-fields, dozens of countries including some developed countries.

FAQ

1. Can I have a sample order of this product?

Yes, we welcome sample order for you to test and check the quality. Mixed samples are acceptable as well.

2. How to Store the Optical Fiber Cable Properly?

Store the drum indoor before using, the drum should place sideways not on the end.

3. What's your payment terms?

We accept T/T,L/C,Western Union,D/P etc. 30% in advance and 70% before shipment.

4. Are you factory direct?

As a professional Cable manufacturer, specialized in Fiber Optic Patch Cord, Fiber Optic PLC Splitter. Our products are mainly exported to Europe, South America, and some other countries and areas.

5. Is there any discount on the product?

We have several production promotion activities every month, welcome to inquire.
